Both our modular and aluminum manifolds come equipped with patent protected “Easy Change” fitting technology. Standard fittings ranging from 1/8” - 1/2” NPT both in male and female configurations. Specials available upon request.
“Easy Change” fittings allow your components to mount closer to one another! There is no need to rotate your components into position with the “Easy Change” manifold. Simply wrench your valve, regulator or any other fluid power component onto our patented “Hex shape design” fitting and sealing "O-RIng" and you are ready to go. Call us at 1-800-526-7661 for more info. Read More >>
Poweraire's Manifold System || Sample Configurations Shown Below || Over 10,000 Configurations Available
5 Station Air Manifold While Inserting Regulators
5 Station Air Manifold After Regulators Have Been Inserted
3 Station Air Manifold While Inserting Valve
3 Station Air Manifold After Valves Have Been Inserted
5 Station Air Manifold Variety
3 Station Regulator Air Manifold
5 Station Air Manifold with Various Manufacturers
6 Station Air Manifold Shut Off Valves
8 Station Air Manifold with 32 Outputs
4 Station Air Manifold w/Vacuum Venturi's
5 Station Air Manifold Flow Controls
4 Station Air Manifold with Tubing and Venturies
6 Station Air Manifold w/2 Females and 1 Male - showing
20 Station Air Manifold w/10 Female Fittings - showing
4 Station Air Manifold w/2 Female Fittings - showing
4 Station Air Manifold w/Male Fittings-Exploded View
Our modular mini blocks are available in one, two and three station sizes. All three mini blocks can be assembled in any order and in any length. All mini blocks can be isolated to themselves or be common to any adjacent block allowing for multiple pressures and multiple medias to be used in one single air manifold with superior air flow capabilities.
Poweraire’s mini blocks and couplings are designed from chemical resistant high impact strength polymers. Each mini block is assembled to one another using one coupling, two 18-8 stainless steel dowel pins to resist block to block torsion and two 304 stainless steel coupling plates to resist both corrosion and tension. All standard “Easy Change” fittings are precision machined from 6061-T6 aluminum and clear anodized to resist corrosion. Modular air manifold end caps come standard with precision machined 6061-T6 aluminum and are clear anodized for corrosion resistance. Both our “Easy Change” fittings and modular end caps can be special ordered with 303 stainless steel making a 100% corrosion resistant manifold package. All fasteners used in the assembly of our standard modular air manifold are 18-8 stainless steel for strength and also to resist corrosion.
Combine vacuum, pressurized gas and low pressure liquid in a single manifold. This saves you valuable machine cabinet space while creating a common mounting platform for components of different size, appearance and function. These exclusive and revolutionary features are found only on our Poweraire Pneumatic Manifold System.
